High efficency double tooth roller coal crusher with high reputation 2PGC600*900 manufacturer from China Henan Zhongcheng Machinery CO,.Ltd

High efficency double tooth roller coal crusher with high reputation

Price:	1000.0~100000.0 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: 2PGC600*900

Production Capacity: 100 every month

Delivery Date: 7~15 working days after the...

Type: Crusher

Roller diameter(mm): 600

Max feed size(mm): 300-600

Motor power(kw): 37

Weight(kg): 7800

Price: negotiable

Means of Transport: Ocean

Packing: Export standard container o...

Application: Others

Brand Name: ZHONGCHENG

Roller length(mm): 900

Output size (mm): 30-150

Capacity(t/h): 80-120

Color: as you need

Certification: ISO:CE

1.Low cost double toothed roller crusher
2.Non-broken materials
3.Reliable performance
4.Simple strucrure
5.ISO9001

High efficency double tooth roller coal crusher withhigh reputation

1. 2PGC double-toothed crusher brief introduction:

Mainly used for the crushing of medium or lower-hardnessmines and rocks with medium or lower rigidity in mine selection, chemicals,cement and building materials industrial production.

2. 2PGC double-toothed crusher working principle:

A roll crusher crushes using compression, with two rollsrotating about a shaft, towards the gap between the rolls. The gap between therolls is set to the size of product desired, with the realization that thelargest feed particle can only be 4 times the gap dimension. The particles aredrawn into the gap between the rolls by their rotating motion and a frictionangle formed between the rolls and the particle, called the nip angle. The tworolls force the particle between their rotating surface into the ever smallergap area, and it fractures from the compressive forces presented by the rotatingrolls.

3. 2PGC double-toothed technical parameter list:

Models	Max.Feed Size(mm)	Output size (mm)	Capacity(m3/h)	Motor Power(kW)	Weight(t)
2PGC-450×500	100	0-25	20	11	3400
	100	0-50	20
	200	0-75	45
	200	0-100	55
2PGC-620×410
2PGC-600×750	300	0-50	60	22	6950
	300	0-75	80
	600	0-100	100
	600	0-125	125
2PGC-600×900	100	0-25	30	37	7230
2PGC-900×900
2PGC-1015×760	80-200	6-50	32-740	90	18011
2PGC-1200×1500	300	100	250	110	52000
